New Agricultural Machinery- Farmland Soil Preparation Machine
Once-over tillage machineThe Once-over tillage machine can complete the pulverize/Smash/Shatter , soil transporting, soil mixing, leveling before sowing, repression, and can be directly prepared flat seedbed, they can improve the efficacy, reduce the cost. After stubble ploughing, the organic soil q......
Send Inquiry
Product Description
Once-over tillage machine
The Once-over tillage machine can complete the pulverize/Smash/Shatter , soil transporting, soil mixing, leveling before sowing, repression, and can be directly prepared flat seedbed, they can improve the efficacy, reduce the cost. After stubble ploughing, the organic soil quality contents rise, soil structure improves, the field improves.
The machine is suitable for growing out robust crop, and the same time you can Obtain greater benefits, All of these can be achieved depends on 1LZ series joint tillage machine, Working width from three point six meters to 7.2m, it can be content with different customer's requirement.
Technical parameters:
The Once-over tillage machine can complete the pulverize/Smash/Shatter , soil transporting, soil mixing, leveling before sowing, repression, and can be directly prepared flat seedbed, they can improve the efficacy, reduce the cost. After stubble ploughing, the organic soil quality contents rise, soil structure improves, the field improves.
The machine is suitable for growing out robust crop, and the same time you can Obtain greater benefits, All of these can be achieved depends on 1LZ series joint tillage machine, Working width from three point six meters to 7.2m, it can be content with different customer's requirement.
Technical parameters:
| Type | 1LZ-3.6 | 1LZ-4.2 | 1LZ-5.4 | 1LZ-7.2 | ||
| Overall dimensions(mm) | L | 6600 | 6600 | 6600 | 7000 | |
| W | 3800 | 4400 | 5600 | 7500 | ||
| H | 1000 | 1000 | 1000 | 1000 | ||
| Max. Working width (m) | 3.6 | 4.2 | 5.4 | 7.2 | ||
| Working depth(mm) | 80-140 | 80-140 | 80-140 | 80-140 | ||
| No. Of disc(PC) | 42 | 50 | 64 | 84 | ||
| Disc of Type (mm) | 460×3 | 460×3 | 460×3 | 460×3 | ||
| Disc spacing(mm) | 170 | 170 | 170 | 170 | ||
| Weight(KG) | 2350 | 2680 | 3320 | 4360 | ||
| Productivity(Ha/h) | 2.28 | 2.66 | 3.33 | 4.44 | ||
| Linkage | Trailed Trailed | |||||
| Trans. Clearance(mm) | ≥160 ≥160 | |||||
| Matched power(Hp) | ≥65 | ≥80 | ≥100 | ≥120 | ||
