Factory Supply Rotary Harrow Disc Harrow Blades Disc Plough Harrow

Product Description

Introduction of disc harrow:

Opposite disc 22 inch blades disc harrow are mainly suitable for stubble removal before farmland plowing, surface compaction, soil crushing after plowing, leveling and maintenance work. It has the characteristics of high working efficiency, reasonable power utilization, strong soil penetration and crushing ability, and unbiased traction of the tractor.

Name	Model	QTY of disc	Cutting width(m)	Tractor power(HP)	Cutting depth	Weight(kg)
Opposed disc harrow	1BQD-1.3	16	1.3	30	140mm	330
	1BQD-1.6	20	1.6	45		390
	1BQD-2.0	24	2.0	60		460
	1BQD-2.4	28	2.4	60-70		560
	1BQD-2.8	32	2.8	70-80		600
	1BQD-3.0	36	3.0	85-100		650

The main difference between disc plough and disc harrow:
1. The structure is different: the disc plough is a single plough blade structure, and the disc harrow is a stringed harrow group structure.

2. The objects and functions of the machine tools are different: the disc plow is mainly used for plowing and plowing operations on uncultivated land, the hanging disc harrow is used for plowing and leveling operations on the plowed land, and the disc heavy harrow is used for plowing and plowing operations on uncultivated land.

3. There are different ways of connecting with the locomotive: the disc plow is a three-point suspension type, and the disc harrow has a large traction type and a three-point suspension type.

4.The structure of the machine and the force during operation are different: the disc plow is similar to the split plow, which is composed of multiple sets of plow legs, and is equipped with a tail wheel device to eliminate partial traction, and the unit is subject to large side pressure during operation; The rake is composed of a traction frame, a rake frame and a plurality of disc groups (multiple discs pierced on a square shaft as a group) arranged symmetrically under the rake frame, and the force is relatively balanced during operation.
