Zoomlion 13 Row Rice Seedlings Throwing Planter
2ZPY-13A Rice seedlings throwing planterAdvanced maturityThere is barely a seedling establishment period, plentiful effective tllers, and a maturity stage 5-8 days in prior to that of machine-transplanted seedlings. Thegeneral output is 10%-20% more than that of transplanted seedlings. Improved work......
Send Inquiry
Product Description
2ZPY-13A Rice seedlings throwing planter
Advanced maturity
There is barely a seedling establishment period, plentiful effective tllers, and a maturity stage 5-8 days in prior to that of machine-transplanted seedlings. Thegeneral output is 10%-20% more than that of transplanted seedlings.
Improved working efficiency
It can throw 13 rows each time, with a working width 2.6m~3.9m and a maximum working efficiency of 15 mu/h which is 1.2~1 .5 times that of 8-row high-speedseedling transplanting machine and around 10 times that of manual seedling throwing.
Revenue increased and expenditure reduced
Machine-thrown rice seedling helps save the cost and increase economic efficiency. The machine-thrown seedlings of one mu can result in a net increase valueof RMB 150-200 considering the rice fertilizer saved and yield increase efficiency.
Enhanced regulatory function
The machine overcomes the disorderly and uneven distribution of manually-thrown seedlings and remedies the non-adjustable leading of seedling transplantingmachine. The rice orderly seedling throwing machine enables an adjustable leading within 20cm~30cm and multiple levels of adjustable row spacing, thus it canrealize a relatively more rational basic seedling volume and planting density compared to machine-transplanted and manually-thrown seedlings and conform tothe technical requirements for the individual transplanting of corresponding rice variety.
Advanced maturity
There is barely a seedling establishment period, plentiful effective tllers, and a maturity stage 5-8 days in prior to that of machine-transplanted seedlings. Thegeneral output is 10%-20% more than that of transplanted seedlings.
Improved working efficiencyIt can throw 13 rows each time, with a working width 2.6m~3.9m and a maximum working efficiency of 15 mu/h which is 1.2~1 .5 times that of 8-row high-speedseedling transplanting machine and around 10 times that of manual seedling throwing.
Revenue increased and expenditure reduced
Machine-thrown rice seedling helps save the cost and increase economic efficiency. The machine-thrown seedlings of one mu can result in a net increase valueof RMB 150-200 considering the rice fertilizer saved and yield increase efficiency.
Enhanced regulatory function
The machine overcomes the disorderly and uneven distribution of manually-thrown seedlings and remedies the non-adjustable leading of seedling transplantingmachine. The rice orderly seedling throwing machine enables an adjustable leading within 20cm~30cm and multiple levels of adjustable row spacing, thus it canrealize a relatively more rational basic seedling volume and planting density compared to machine-transplanted and manually-thrown seedlings and conform tothe technical requirements for the individual transplanting of corresponding rice variety.
| Model | Unit | 2ZPY-13A | |
| Driving type | / | Four-wheel drive | |
| Dimension(L×W×H) | mm | 3890*2160*2810 | |
| Minimum ground clearance | mm | 440 | |
| Weight | kg | 992 | |
| Engine | Model | / | E3112-UP08/E3112-UP10 |
| Type | / | Four cylinders, in line, water cooled | |
| Total exhaust | L | 1.123 | |
| Output / rotational speed | kW/ r/min | 15.3/2500 | |
| Fuel consumption | g/kW·h | ≤262 | |
| Fuel | / | No.0 diesel | |
| Tank capacity | L | 28 | |
| Variable speed gear number | / | Three steps forward and three back | |
| Seedling throwing system | Starting mode | Electric motor start | |
| Position of seedling throwing device | / | Rear part | |
| Seedling throwing and lifting mode | Hydraulic type | ||
| Seedling throwing square | Free fall along seedling throwing belt | ||
| Number of rows of seedling throwing | row | 13 | |
| Row spacing | mm | 210~320 | |
| Planting spacing | mm | 120,130,150,160,170,180,220,240 | |
| Efficiency | (ha / hour) | 0.5-0.8 | |
| Seedling condition | Seedling species | / | Potted seedling |
| Seedling height | mm | 70~240 | |
| Leaf number | / | 2~4 | |
| Number of seedling trays | / | 20 | |
