Farm Machine Hydraulic Boom Sprayer Tractor Implement
3WPX-800 type hanging sprayer3WPX-800 series of sprayer is suitable for spraying the medicament for the planter of bean, corn, cotton, grain.Also for lawn,fruiter,vegetable, road side tree. The capacity could be 800L, the spraying width could be 7.5m with 22hp.Advantages:This kind of boom sprayer is......
Send Inquiry
Product Description
3WPX-800 type hanging sprayer
3WPX-800 series of sprayer is suitable for spraying the medicament for the planter of bean, corn, cotton, grain.
Also for lawn,fruiter,vegetable, road side tree. The capacity could be 800L, the spraying width could be 7.5m with 22hp.
Advantages:
•This kind of boom sprayer is a tractor mounted sprayer.
•Wide working scope,spraying for bean,cotton,corn etc.
•Wide spraying with to be 18m max.and the working angle of this tractor sprayer could be adjusted.
•The capacity of mounted boom sprayer could be adjusted to meet different need from the user.
| Model | 3WPX-800 type hanging sprayer | Pump Type | Diaphragm pump (four-cylinder) |
| Power | ≥22KW (30 hp) | Pump Pessure | 3.0Mpa |
| Mixing Method | Circulating water mixing | Pump Flow | 160L / min |
| Folding Method | Hydraulic folding | Pump Speed | 500-600r / min |
| Vertical Height | 0.5m | Tank Capacity | 800L |
| System Work Pressure | 0.3-0.5Mpa | Spray Width | 12m |
| 3 Filtration System | Tank inlet, pump inlet, nozzle | Spray Height | 0.5m |
| Operating Efficiency | 18-24 acres / hour | Nozzle Model | No.3 |
| Walking Speed | 4-20Km / h | Spray Angle | 110 ° |
| Overall Dimension | 2900 mm x 1650 mm x 1600 mm | Nozzle Flow | 1.2L / min |
| Weight | 150kg | Water Tank | 15L |
Q:Are you a factory or trading company?
A:We are a factory.
Q:How does your factory do regarding quality control?
A:Quality is priority. we always say great importance to quality controlling from the very beginning to the very end.
Q:Do you have a product accessory?
A:Yes, we have the accessories of the product.
Q:Can you customize the product?
A:We can customize the product.
Q:What's your payment terms?
A:Payment terms is T/T or L/C,We accept all reasonable payment.
Q:How about delivery time of your machine?
A:The delivery time is in 60 working days. It depending your quantity.
